2/1 Channel MOSFET Powered Amplifier – XPR522



Authorized Retailer:



SKU: XPR522 Categories: ,

YouTube video

mosfet

The MOSFET power supply offers the amplifier a higher efficiency and longer lifespan for a greater user experience.

lowprofile

The low profile build is designed to be unobtrusive and helps with installation flexibility; perfect for installing in small spaces.

600w

This product is carefully crafted for efficient and accurate bass, providing you with great power handling.

xpr522 wiring diagram
xpr522 wiring diagram
xpr522 wiring diagram

Required for installation:

8 AWG amplifier installation kit, 16 AWG speaker wire (for speakers), 12 AWG speaker wire (for subwoofers), speakers and/or subwoofer(s).

Amplifier installation kit, subwoofers, speakers, headunit, and speaker wire sold separately.

Speaker Outputs

Class

Inputs

,

Bridgeable

2 Ohm Stable Stereo Operation

Frequency Response

Power

, ,

Signal to Noise Ratio

Total Dynamic Power

Amplifier Outputs

Crossover

Variable

Impedance

,

Gain Adjustment

Adjustable Bass Boost

Power Supply

Dimensions

Features

Features:

  • Low and high level inputs
  • Variable gain adjustment (200mV ~ 6V)
  • Selectable crossover (high pass/low pass/full range)
  • Variable low/high pass crossovers
  • Bass boost (0, 6, 12dB)
  • PWM MOSFET power supply
  • Bridgeable operation for subwoofer applications
  • 2 Ohm stable stereo operation
  • Class AB output design
  • Stereo/bridged simultaneous operation

Specifications:

  • Power Output:
  • 150 Watts x 2 channels @ 4 ohms
  • 300 Watts x 2 channels @ 2 ohms
  • 600 Watts x 1 channel @ 4 ohms (bridged)
  • Total dynamic power: 600 Watts
  • Signal to noise ratio: 75dBA (reference: 1 Watt into 4 ohms)
  • Frequency response: 20Hz ~ 20kHz
  • Amplifier dimensions: 2.76” (H) x 9.09” (W) x 10.55“ (D)
  • Typical installation dimensions: 3.75”(H) x 10.25” (W) x 11.5” (D)
